2D Drafting & Layout

Precise 2D architectural, structural, and MEP layouts using AutoCAD and Electrical AutoCAD to international drafting standards.

3D BIM Modeling

Full-featured 3D BIM models in Autodesk Revit for Architecture, Structure, and MEP — enabling coordination, visualization, and analysis.

Clash Detection

Multi-discipline clash detection and coordination using Navisworks to identify and resolve design conflicts before construction.

Quantity Takeoff

Accurate material quantity takeoffs and BOQ generation directly from BIM models to support cost estimation and planning.

MEP Systems Design

Mechanical, Electrical, and Plumbing (MEP) layout design and coordination in Revit MEP ensuring code compliance and spatial efficiency.

Architectural Visualization

High-quality 3D renderings and walkthroughs using SketchUp Pro and V-Ray to communicate design intent to clients and stakeholders.

Technical Skills

Software Proficiency

AutoCAD / Electrical AutoCAD 99%

Autodesk Revit (Architecture) 99%

Revit Structure & MEP 99%

Navisworks (Clash Detection) 99%

SketchUp Pro 99%

V-Ray Rendering 99%

Core Competencies

2D Drafting 3D Modeling BIM Coordination MEP Systems Quantity Takeoff Clash Detection Architectural Revit Structural Revit Construction Docs Building Information Modeling Navisworks SketchUp V-Ray AutoCAD MEP Layout Electrical Drafting

My Projects

1 / 2

Commercial Mall — Revit MEP

Revit Architecture Revit MEP Electrical BIM

Developed a full Revit architectural 3D model of a large-scale commercial shopping mall.
Designed and coordinated the complete electrical MEP layout within the Revit BIM environment.
Ensured spatial coordination between architectural elements and electrical systems.

1 / 3

Commercial Building — MEP Project

Revit MEP Electrical Mechanical Plumbing Navisworks

Modeled complete MEP systems (Electrical, Mechanical/HVAC, Plumbing) for a multi-floor commercial building.
Performed multi-discipline clash detection using Navisworks to resolve design conflicts.
Produced coordinated 2D MEP drawings and BOQ for project estimation.

Residential House — SketchUp Render

SketchUp Pro V-Ray 3D Modeling Visualization

Created a fully detailed 3D model of a residential house in SketchUp Pro.
Produced high-quality photorealistic exterior renders using V-Ray with materials and lighting.
Delivered elevation views and 3D visualization outputs to communicate design intent.

Residential House - 2D AutoCAD Floor Plan

Residential House — 2D AutoCAD Layout

AutoCAD 2D Drafting Floor Plan Construction Docs

Drafted a detailed 2D floor plan of a residential house using AutoCAD to professional standards.
Included dimensions, annotations, wall thicknesses, door/window schedules, and north arrow.
Prepared construction-ready drawings for client presentation and contractor use.

School Building — Lighting Layout Plan

Electrical AutoCAD Lighting Design MEP 2D Drafting

Designed a 2nd-floor lighting layout plan for an institutional school building using Electrical AutoCAD.
Planned fixture placement, circuit routing, and load distribution ensuring code compliance.
Produced a fully annotated electrical drawing ready for tender and site installation.

1 / 3

Residential Apartment — BIM Project

Revit Architecture Revit Structure Revit MEP Electrical HVAC Plumbing

Modeled a multi-storey apartment (G+3) in Revit covering Architecture, Structure, and MEP disciplines.
Prepared 2D floor plans for all floors, 3D elevation renders, and full MEP layouts.
Conducted clash detection using Navisworks and generated quantity takeoff reports.

Education & Certification

Nov 2021 – April 2025

Bachelor of Engineering

Mount Zion College of Engineering and Technology

First Class with 7.30 CGPA

Jun 2020 – May 2021

Higher Secondary

St. Joseph Matriculation Higher Secondary School

Completed with 79.70% Percentage

Certification

Master Course in Building Information Modeling (BIM)

Professional BIM Institute

AutoCAD · Revit Architecture · SketchUp Pro · Revit Structure · Quantity TakeOff · Revit (MEP) · NavisWorks
